Engineered for the harshest industrial environments, our Heavy-Duty FRP (Fiberglass Reinforced Plastic) Chemical Storage Tanks provide a superior solution for the containment of aggressive acids, alkalis, and solvents. Unlike traditional metal tanks that require frequent maintenance or rubber linings, our filament-wound fiberglass tanks offer a monolithic, leak-proof structure with inherent corrosion resistance throughout the vessel wall.
Designed to replace stainless steel and lined-steel vessels, this corrosion-resistant acid & alkali vessel is ideal for storage of sulfuric acid, hydrochloric acid, sodium hydroxide, and wastewater, ensuring long-term safety and compliance with environmental regulations.
Advanced Filament Winding Technology: Manufactured using computer-controlled micro-winding processes, ensuring a high glass-to-resin ratio for maximum structural strength and hoop tensile stress resistance.
Superior Chemical Resistance: The inner liner is fabricated using premium Vinyl Ester or Epoxy resins (such as Derakane 411/470 equivalent), specifically selected based on your chemical medium to prevent corrosion, blistering, or delamination.
Standards Compliance: Fully designed and manufactured in accordance with ASTM D3299 (Filament-Wound Glass-Fiber-Reinforced Thermoset Resin Corrosion-Resistant Tanks) and ASME RTP-1 standards.
Maintenance-Free Durability: The exterior features a UV-resistant, resin-rich topcoat that withstands weathering, requiring no painting or rust-proofing, with a design life exceeding 20 years.
Customizable Configurations: Available in Vertical Flat Bottom, Vertical Cone Bottom, Horizontal, and Double-Wall designs to suit specific site requirements.
We provide rigorous engineering based on Finite Element Analysis (FEA) to ensure safety under specific loads (wind, seismic, internal pressure).
| Parameter | Specification Details |
| Material Construction | Fiberglass Reinforced Plastic (FRP / GRP) |
| Manufacturing Process | Helical & Hoop Filament Winding (Micro-controlled) |
| Resin Options | Premium Vinyl Ester, Isophthalic Polyester, Food-Grade Resin |
| Corrosion Barrier | C-Glass or Synthetic Veil + Resin Rich Layer (Min 2.5mm) |
| Design Standards | ASTM D3299, ASTM D4097, EN 13121, ASME RTP-1 |
| Capacity Range | 1 m³ to 200 m³ (Custom sizes available up to 4000mm diameter) |
| Operating Temperature | -40°C to +120°C (Dependent on resin selection) |
| Specific Gravity (SG) | Designed for 1.0 to 2.2 SG (Suitable for heavy concentrated acids) |
| Accessories Available | FRP Flanges, Manways, Level Gauges, Ladders & Cages (OSHA compliant), Lifting Lugs, Baffles |
Our Heavy-duty FRP vessels are trusted by engineers across various sectors for industrial chemical containment:
Chemical Processing: Bulk storage of Hydrochloric Acid (HCl), Sulfuric Acid (H2SO4), Nitric Acid (HNO3), and Sodium Hypochlorite.
Water & Wastewater Treatment: Storage for Coagulants (PAC/PAM), pH neutralization tanks, and leachate storage.
Metal Finishing & Pickling: Acid pickling baths, electroplating solution circulation tanks.
Food & Beverage: Fermentation tanks and storage for soy sauce/vinegar (using FDA-compliant food-grade resins).
Petrochemical: Storage of drilling fluids, brine water, and oil-water separation.
Every tank undergoes rigorous inspection before shipment to ensure zero defects:
Hydrostatic Leak Test
Barcol Hardness Test (Cure verification)
Acetone Sensitivity Test
Ultrasonic Thickness Measurement
Visual Inspection for air bubbles or dry spots
Secure your facility with the most durable FRP Chemical Storage Tanks on the market.
[Contact Us Today] for a custom drawing and quotation based on your chemical specifications.
